CP Plus HD 2.4MP illumax Dual Light Bullet CCTV (CP-URC-TC24PL3C-L)

Image Sensor: 2.4MP PS CMOS Image Sensor

Maximum Resolution: 1920 × 1080 pixels

Lens Options: Fixed 3.6mm lens (2.8mm and 6mm optional)

Aperture: F2.0

Minimum Illumination:

Color: 0.02 lux @ F2.0 (30 IRE)

B/W: 0.002 lux @ F2.0 (30 IRE)

0 lux with IR on

Shutter Speed:

PAL: 1/25s to 1/100,000s

NTSC: 1/30s to 1/100,000s

Day/Night Functionality: Auto (ICR) / Color / B/W

Backlight Compensation: BLC / HLC / DWDR

Noise Reduction: 2D DNR

White Balance: Auto, Area White Balance

Gain Control (AGC): Auto / Manual

Angle of View:

3.6mm lens: Horizontal 80°, Vertical 43°, Diagonal 94°

2.8mm lens: Horizontal 100°, Vertical 54°, Diagonal 117°

6mm lens: Horizontal 43°, Vertical 24°, Diagonal 50°

DORI Distance (3.6mm lens):

Detect: 55.0m

Observe: 22.0m

Recognize: 11.0m

Identify: 5.5m

IR Range: Up to 30 meters

Warm Light Range: Up to 20 meters

IR Control: Auto / Manual

IR Mode: Smart IR & Warm Light, Warm Light Mode, IR Mode

Mirror Function: Supported

Privacy Masking: Up to 8 areas (rectangular)

OSD Menu: Multi-language support

Audio: Built-in Microphone


? Video & Connectivity

Video Output: Selectable CVI / TVI / AHD / CVBS via one BNC port

Supported Resolutions:

2.4MP (1920 × 1080)

960H (960 × 576 / 960 × 480)

Frame Rates:

CVI: PAL 2.4MP @25fps, NTSC 2.4MP @30fps

AHD: PAL 2.4MP @25fps, NTSC 2.4MP @30fps

TVI: PAL 2.4MP @25fps, NTSC 2.4MP @30fps

CVBS: PAL 960H, NTSC 960H

Compatibility: Supports multiple video formats for seamless integration with various DVRs


?? Mechanical & Environmental

Casing: Plastic

Dimensions: Approximately 85.0 mm × 85.0 mm × 85.0 mm

Weight: 0.24 kg

Power Supply: 12V DC ±30%

Power Consumption: Max 2.1W (with IR LED on)

Operating Temperature: -40°C to +60°C (-40°F to +140°F)

Operating Humidity:
