CP-DNW-GPU4G2-48
6 Ports Switch with 4 Gigabit PoE Ports & 2 Gigabit Uplink Ports
4, 1000Mbps; RJ45 ports; Max. 30W Output of Single PoE Port
Support IEEE802.3i/802.3u/802.3x/802.3ab
Uplink Port: 2, 1000Mbps; Transmission Distance: 0-100m
PoE Power Budget: 48W

Switch Capacity
12 Gbps Full duplex
Uplink Ports
2, 1000Mbps; Transmission Distance: 0-100m
PoE Power Budget
48W
Anti-thunder Level
Common mode: 2KV Differential mode: 2KV
ESD
Air discharge: 1.5KV Contact discharge: 1.5KV
Ethernet Port Light
Light off: Link is disconnected Red light on: Powering but data disconnected Light flash quickly: Data Transmitting
Network Port
6
Transmission Distance
0-100m/100 Mbps
PoE Ports
4, 1000Mbps; RJ45 ports; Max. 30W Output of Single PoE Port Transmission distance:0~100m
PoE Power Supply
1/2(+), 3/6(-)
PoE Standard
IEEE802.3af, IEEE802.3at
Packet Forwarding Rate
1.488Mpps/port
MAC Address List
2K
Power Source
Built-in Power Supply, Input: 110-264V AC, 50/60Hz
Power Consumption
<5W
Operating Temperature
-10°C~ -50°C
Humidity
10%-95% , non-condensing
Storage Temperature
-40°C~70°C
Dimension
202mm x 140mm x 45mm (L x W x H)
